| Model | FB12C | FB14C | FB16C | FB18C | FB20C | FB22C | FB24C | FB25C | FB26C | FB28C | FB30C | FB32C | FB34C | FB36C |
| Working Height | 12M | 14M | 16M | 18M | 20M | 22M | 24M | 25M | 26M | 28M | 30M | 32M | 34M | 36M |
| Max Platform Height | 10M | 12M | 14M | 16M | 18M | 20M | 22M | 23M | 24M | 26M | 28M | 30M | 32M | 34M |
| Load Capacity | 300KG | 300KG | 250KG | 250KG | 250KG | 250KG | 250KG | 250KG | 250KG | 250KG | 250KG | 250KG | 250KG | 250KG |
| Platform Size | 1.3*0.7m or 1.2*0.8M optional free | |||||||||||||
| Working Radius | 6M | 7M | 9M | 11M | 12.5M | 13M | 13M | 11.5M | 11.5M | 11.5M | 11.5M | 11.5M | 11.5M | 13.5M |
| Net Weight | 2200KG | 2400KG | 2600KG | 2800KG | 3600KG | 4100KG | 4300KG | 4900KG | 4900KG | 5300KG | 5500KG | 6500KG | 6800KG | 6800KG |
| Machine Size(L*W*H) | 4.1*0.9*2.1M | 4.7*0.9*2.1M | 5.55*1*2.1M | 5.7*1*2.25M | 6.1*1*2.25M | 6.7*1*2.25M | 5.7*1.3*2.3M | 6.1*1.5*2.3M | 6.2*1.5*2.3M | 6.3*1.3*2.3M | 6.5*1.3*2.3M | 6.8*1.35*2.3M | 7.5*1.5*2.3M | 7.5*1.5*2.3M |
| Outrigger Span | 4.2*4.2M | 4.24.2M | 4.2*4.5M | 6.5*6.5M | 6.5*6.5M | 6.5*6.8M | 6.5*6.8M | 6.8*5.5M | 6.8*5.5M | 6.8*5.5M | 6.8*5.5M | 6.8*5.5M | 6.8*5.5M | 6.8*5.5M |
| Wind Resistance | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 | ≤5 |
| Working Temp | -30~65°C environmental temperature | |||||||||||||
| Telescopic Boom | Equipped | |||||||||||||
| Hydraulic JlB | Equipped | |||||||||||||
| Rotation | 360 degree continuous rotation,high configurations | |||||||||||||
| Control Way | Wireless remote control + High End Stainless Steel Electrical Control Box. We have control cables for the remote control on basket.f there is signal interference in your project site,you can plug in. | |||||||||||||
Vehicle "CAN" Control System | Use advanced “CAN" system ,which is widely used for cars in Europe and America,very stable.it has Self-diagnosis and memory function,can show errors in various language directly,like English,Spanish,Germany,Russia,rather than just an error code. | |||||||||||||
Our Brand Story “FasterLift” | "Fasterlift" is a famous brand in China,mainly produce boom lift,scissor lift,spider crane,vacuum lifters and lift tablesAs a professional manufacturer with 20years production experience,we can offer you the reliable machineand matured technical support, We have a 80,000 square meter industrial park,53,000 squaremeter factory buildings,a real professional and powerful manufacturer. | |||||||||||||
| Proportional Valve | Use America “Hydra-force” hydraulic proportional valve,high precise control | |||||||||||||
| Up/Down speed | Infinitely variable speeds.Proportional valve control | |||||||||||||
| Walking Speed | Turtle and rabbit speed,dual speed control | |||||||||||||
